Description
Our Panel Mount Flashers contain all flashing and load switching circuitry in a compact cube style package. These flashers may be used for flashing two tungsten lamps, LED, or inductive loads. Single circuit operation is possible by connecting only one load, thereby providing a spare circuit should overload of the connected circuit occur. Panel Mount Flashers are the most reliable and cost effective way to operate your warning beacon systems and meets or exceeds all MUTCD specifications for U.S. roads and highways.
These are chassis mount flashers with a small footprint of just 1¾ inches by 2¼ inches. Mounting on a flat metal surface is simple through the two #8 clearance holes provided. Usage of a high thermal conductivity grease is required between the flasher and chassis to help dissipate heat for long trouble-free operation. Besides mounting to a cabinet wall, these flashers may be used to upgrade electro-mechanical flashers to solid state reliability. These flashers are epoxy filled giving a rugged unit capable of withstanding the harsh environmental performance requirements of NEMA and 170 Type specifications.
- Power Input: 6 – 24 Volts DC
- Power Output: 10 Amps (with adequate heat sinking at 77 °F.)
- Flash Rate: 55 fpm
- 2 Year manufacturer warranty
- Proudly Made in the USA
Dimensions: 1.75″ L x 2.25″ W
Spec Sheet: Download (PDF)
Photo for reference only. Actual product may vary slightly.
